Chapter two is about programming technology. In this section, we will explore the concept of function pointer arrays, which is a crucial aspect of advanced programming. For instance, imagine you're building a pocket calculator that reads two numbers, op1 and op2, along with an operator, oper. Traditionally, one might use a switch statement to check the operator and decide which function to call:
```c++
switch(oper) {
case '+':
result = op1 + op2;
break;
case '-':
result = op1 - op2;
break;
//... and so on for many more cases
}
```
Clearly, for a calculator with hundreds of operators, this approach becomes cumbersome and inefficient. Instead, you could utilize a transfer table, which is essentially an array of function pointers. Each element in this array would hold the address of a specific function. Let’s define a pointer type PF for a function that returns a double and takes two double parameters:
```c++
typedef double (*PF)(double, double);
```
Now, suppose you need to declare an array called `oper_func` with four elements to store the addresses of four functions. Here's how you could define such an array:
```c++
PF oper_func[4] = {ADD, SUB, MUL, DIV};
```
In this example, `PF` defines the type of the array elements as pointers to functions, while `oper_func` is an array of these function pointers. Even though the syntax looks slightly different, the functionality remains identical.
Assigning values to elements in a function pointer array works just like assigning values to elements in a regular array. For example:
```c++
oper_func[0] = ADD;
```
This is similar to assigning any other array element. Function pointer arrays can also be initialized during their declaration:
```c++
PF oper_func[] = {ADD, SUB, MUL, DIV};
```
When creating a transfer table, it’s important to ensure that the prototypes of the functions being pointed to are declared before the array itself. Here's an example:
```c++
double ADD(double a, double b) { return a + b; }
double SUB(double a, double b) { return a - b; }
double MUL(double a, double b) { return a * b; }
double DIV(double a, double b) { return a / b; }
PF oper_func[] = {ADD, SUB, MUL, DIV};
```
In this case, the initial values in the array automatically determine the size of the array. So, there’s no need for a separate initialization step. It’s critical that the order of the function names in the initialization list matches the integer codes used by the program to represent each operator. For instance, ADD, SUB, MUL, and DIV might correspond to 0, 1, 2, and 3, respectively. The function call would look like this:
```c++
result = oper_func[oper](op1, op2);
```
Here, the `oper` variable selects the appropriate function pointer from the array, and the function call operator executes the selected function.
Alternatively, you can omit the size of the array and let the compiler determine it based on the initialization list:
```c++
PF oper_func[] = {ADD, SUB, MUL, DIV};
```
The number of initial values in the braces will define the size of the array. This method applies equally well to initializing other types of arrays.
